Punch 8″ P2 4-Ohm DVC Subwoofer
P2D4-8
The Rockford Fosgate P2 8” subwoofer continues “The PUNCH” tradition. The P2D4-8 features a Dual 4-Ohm voice coil, 250 Watts RMS power handling, and can accommodate a grille insert using the included cast aluminum trim ring.
FEATURES AT A GLANCE
1 Year Warranty
Kevlar fiber reinforced paper cone
Diamond cut cast aluminum trim ring with optional grille
StampCast basket with integrated spider venting
Custom 10-AWG nickel plated push terminals
Protective PVC textured magnet cover
Extended pole piece and bumped vented backplate
Dual linear spider with embedded 16 AWG tinsel leads
High-temp voice coil with spun-laced Nomex® re-inforcement collar
Magnet Weight (oz)49 oz. (1.38 kg.)
Sd (cm2)221
Mounting Depth4.76 in. (120.8 mm)
Power Handling (Watts RMS)250 Watts RMS
500 Watts Max
Size8″
Nominal ImpedanceDual 4-Ohm
Speaker ConnectorDual 10 AWG compression
Shipping Weight10.763 Lbs. (4.88 kg.)
Voice Coil Diameter2.25″ (57.7 mm)
SPL (dB @ 1w/1m)83
Fs (Hz)43
Cutout Diameter7.13 in. (181 mm)
Re (Ohms)6.90
Qts0.52
Qes0.58
Qms5.40
Vas (Liters)9.9
Le (mH)4.3
Xmax (mm)7.7
Woofer Displacement0.042 cu. ft. (1.2 Liters)
CEA-2031 CompliantCEA-2031 Guidelines
Subwoofer TypeStandard
Voice Coil TypeDual Voice Coil
Sealed Box Volume (Vb)0.23 cu. ft. (6.5 Liters)
Vented Box Volume (Vb)0.65 cu. ft. (18.4 Liters)

Κατασκευαστής	Rockford Fosgate
Μέγεθος subwoofer	8”
Brand	Rockford Fosgate
