P3D2-12

Punch 12″ P3 2-Ohm DVC Subwoofer
P3D2-12
The P3D2-12 is the best performing Rockford Fosgate Punch series subwoofer. Built to max out your car audio system, the P3 12” features Dual 2-Ohm voice coils (DVC), 600 Watts RMS of power handling, and accommodates a grille insert using the included cast aluminum trim ring.
FEATURES AT A GLANCE
High-temp voice coil with spun-laced Nomex® re-inforcement collar
Custom 10-AWG nickel plated push terminals
Dual linear spider with embedded 16 AWG tinsel leads
Anodized aluminum cone and dustcap
Extended pole piece and bumped vented backplate
Diamond cut cast aluminum trim ring with optional grille
StampCast basket with integrated spider venting
Protective PVC textured magnet cover
1 Year Warranty
Power Handling (Watts RMS)600 Watts RMS
1200 Watts Max
Speaker ConnectorDual 10 AWG compression
Shipping Weight20.9 Lbs. (9.48 kg)
Magnet Weight (oz)96 oz. (2.73 kg.)
Size12″
Nominal ImpedanceDual 2-Ohm
Mounting Depth6.66 in. (169.3 mm)
Voice Coil Diameter2.5″ (65.5 mm)
Woofer Displacement0.106 cu. ft. (3.0 Liters)
Re (Ohms)3.20
SPL (dB @ 1w/1m)85
Fs (Hz)26.5
Qts0.49
Qes0.53
Qms6.70
Cutout Diameter11.25 in. (285 mm)
Le (mH)4.25
CEA-2031 CompliantCEA-2031 Guidelines
Vas (Liters)57.7
Xmax (mm)15.2
Sd (cm2)570
Subwoofer TypeStandard
Voice Coil TypeDual Voice Coil
Sealed Box Volume (Vb)1.02 cu. ft. (28.8 Liters)
Vented Box Volume (Vb)1.79 cu. ft. (50.6 Liters)
