Punch 10″ P1 4-Ohm SVC Subwoofer
P1S4-10
Rockford Fosgate P1 10” is the first in a family of famous “Punch” subwoofers. The P1S4-10 features a 4-Ohm voice coil, 250 Watts RMS power handling, and can accommodate a grille insert using the included soft touch ABS trim ring.

FEATURES AT A GLANCE
StampCast basket with integrated spider venting
Kevlar fiber reinforced paper cone
Rubberized ABS trim ring with optional grille
Custom 10-AWG nickel plated push terminals
Linear spider with embedded 16 AWG tinsel leads
High-temp voice coil with spun-laced Nomex® re-inforcement collar
Extended pole piece and bumped vented backplate
1 Year Warranty
Protective PVC textured magnet cover

Magnet Weight (oz)

45 oz. (1.28 kg.)

Subwoofer Type

Standard

Voice Coil Type

Single Voice Coil

Nominal Impedance

4-Ohm

Size 10″

CEA-2031 Compliant

Power Handling (Watts RMS) 250 Watts RMS
500 Watts Max

Qms

3.00

Qes

0.61

Qts

0.52

Fs (Hz)

30

Speaker Connector

Dual 10 AWG compression

Re (Ohms)

3.6

Voice Coil Diameter

2.0″ (51.6 mm)

Vas (Liters)

40

SPL (dB @ 1w/1m)

85

Sd (cm²)

370

Le (mH)

2.81

Xmax (mm)

9.0

Mounting Depth

5.33 in. (135.4 mm)

SPL (dB @ 2.8v/1m)

88

Cutout Diameter

9.14 in. (232 mm)

Woofer Displacement

0.056 cu. ft. (1.6 Liters)

Sealed Box Volume (Vb)

0.59 cu. ft. (16.7 Liters)

Vented Box Volume (Vb)

1.4 cu. ft. (39.6 Liters)

Shipping Weight

10.9 Lbs. (4.94 kg)

Κατασκευαστής	Rockford Fosgate
Μέγεθος subwoofer	10”
Brand	Rockford Fosgate
